XY9002


XY9002 is a multi-system dual frequence GNSS receiver.

XY9002 adopts advanced software and hardware combined low-power design. Additionally, it implements advanced anti-multipath and anti-interference RF front-end, significantly improving actual positioning and TTFF performance. XY9002 is widely used in automotive, wearable devices, and other accurate positioning applications.

Product Advantage

    • b4_icon01.svg

      High sensitivity

      The acquisition sensitivity is greater than -148dBm, and the tracking sensitivity is greater than -165dBm.

    • b4_icon01.svg

      Excellent multipath rejection

      Supports L1+L5 dual-band,  has excellent multipath rejection.

    • b4icon02-193.svg

      Low-power consumption

      L1/L5 Continuous tracking mode: 20 mA

      L1 Continuous tracking mode: 12 mA

      Sleep mode: 14 μA

    • b4icon02-193.svg

      AGNSS is supported.

Basic Parameter

    • Multi-system dual-band joint positioning

      L1 band supports GPS L1, Beidou B1I, Beidou B1C, Galileo E1, QZSS L1, GLONASS G1 L5 band supports GPS L5, Beidou B2A, Beidou B2B, Beidou B2I,Galileo E5, QZSS L5, IRNSS

    • Processor

      32-bit MCU

    • Encapsulation

      QFN 4mm*4mm

    • Hardware peripheral

      • 17 GPIOs
      • 3x UART; 1x SPI; 1x I2C

    • Operating temperature

      -40°C to +85°C
